Covestro PC+ASA Bayblend W90 XG UV-stabilized,good surface finish

Covestro PC+ASA Bayblend W90 XG UV-stabilized,good surface finish

Standard grades
Non reinforced PC+ASA-Blend; Vicat/B 120 temperature = 115°C; UV-stabilized; very good surface finish

Covestro Certified Supplier / Support Customized / Factory-Direct Supply

Bayblend W90 XG

118.3KB

Get Datasheet Get Datasheet

Category:

Key words:

Covestro W90 XG

Bayblend W90 XG

PC ASA W90 XG

Characteristic

UV-stability

Good surface finish

Main physical property

Standard grades
Non reinforced PC+ASA-Blend; Vicat/B 120 temperature = 115°C; UV-stabilized; very good surface finish

Rheological properties

Property		Test Condition	Unit	Standard	typischer Wert
C	Melt volume-flow rate	260℃/5kg	cm³/10 min	ISO 1133	34
C	Total shrinkage, normal	60x60x2 mm	%	ISO 294-4	0.5-0.7
C	Molding shrinkage, normal	60x60x2 mm	%	ISO 294-4	0.5-0.7

Mechanical properties (23 °C/50 % r. h.)

Property		Test Condition	Unit	Standard	typischer Wert
C	Tensile modulus	1 mm/min	MPa	ISO 527-1,-2	2830
C	Yield stress	50 mm/min	MPa	ISO 527-1,-2	65
C	Yield strain	50 mm/min	%	ISO 527-1,-2	4
	Stress at break	50 mm/min	MPa	ISO 527-1,-2	50
	Strain at break	50 mm/min	%	b.o. ISO 527-1,-2	50
	Flexural modulus	2 mm/min	MPa	ISO 178	2840
	Flexural modulus	2 mm/min	MPa	b.o. ISO 178	100
	Flexural strain at flexural strength	2 mm/min	%	ISO 178	5
	Flexural stress at 3.5 % strain	2 mm/min	MPa	ISO 178	85
	Izod notched impact strength	23 °C	kJ/m²	ISO 180/A	14
	Izod notched impact strength	-30 °C	kJ/m²	ISO 180/A	7
C	Puncture impact properties - maximum force	23 °C	N	ISO 6603-2	4800
C	Puncture impact properties - maximum force	-30 °C	N	ISO 6603-2	4250
C	Puncture energy	23 °C	J	ISO 6603-2	45
C	Puncture energy	-30 °C	J	ISO 6603-2	20
